Home » TCR Acrylic Dome Sun Tunnel Skylight with Rigid Tube - 14"
VELUX

TCR Acrylic Dome Sun Tunnel Skylight with Rigid Tube - 14"

In stock
SKU: TCR 014 0000
Pickup available at Elk Grove Village, Illinois
$472.00

  • Description

    Acrylic Dome Sun Tunnel Skylight

    Before placing an order, please contact us by phone: at (630)-233-4514 or email us: at sales@attic-ladders.com to confirm the availability of the selected model.

    VELUX Sun Tunnel® Skylight is a great solution to brighten space with natural light. Installation can end within an afternoon. All that makes a most inexpensive solution to bring light into dark rooms.

    Main features:

    - UV resistant dome is specially designed to capture and transfer pure natural light with no color change

    - Adjustable pitch adapter allows for a faster installation and more light

    - VELUX Flexi Loc tube system allows easy tube assembly

    - Rigid tunnel system is recommended for straight, unobstructed applications.



    Technical Specification:

    Tunnel length with kit 48”
    Maximum recommended installation length 30’
    Product Weight 28.32 LBS
    Rough Opening-Roof Deck 16 3/4" x 16 3/4" (425 mm x 425 mm)
    Outside Flashing 20 7/8" x 20 7/8" (530 mm x 530 mm)
    Roof Pitch Range 0° - 30°
    Air Leakage 0.5 L/S/M2 (0.09 CFM/FT2)
